Chevrolet Equinox II (2009-2015) ign logic Wiring diagram
This page shows the only wiring diagram for the component.ign logic, which is found in the car Chevrolet Equinox II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign logic (1 of 1)
11 6 KEY SIGNAL KEY SPLY VOLT
3 2 GREEN LED SIG
BACKUP SPLY
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BREAKOUT)
BRN/WHT WIRE
CAMERA + SIG CAMERA - SIG
COMP SW
DISPLAY
DK GRN/WHT WIRE
EMERGENCY IND
EMERGENCY SWITCH
GREEN LED
GROUND BACKUP LMP SPLY VOLT
IGN LOGIC
INSIDE REARVIEW MIRROR
LT BLU WIRE
LT GRN WIRE
LT GRN/BLK WIRE
MIRROR DIMMING
NAVIGATION SYSTEM
ONSTAR IND
ONSTAR SWITCH
PHONE IND
PHONE SWITCH
PNK WIRE
POWER DISTRIBUTION SYSTEM
RED LED SIG WIRE
RED LED WIRE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (W/ ONSTAR) (CENTER OF DASH)
TEMP SW
YEL/BLK WIRE
Go to component -> Electrochromic mirror circuit, with rear view camera -> IGN LOGIC
