Chevrolet Equinox II (2009-2015) 9 1 8 dimmer sw sig batt positive volt dimming control Wiring diagram
This page shows the only wiring diagram for the component.9 1 8 dimmer sw sig batt positive volt dimming control, which is found in the car Chevrolet Equinox II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 9 1 8 dimmer sw sig batt positive volt dimming control (1 of 1)
22 7 13 PARK LAMPS SIG LOW REFERENCE 5-VOLT REFERENCE
9 1 8 DIMMER SW SIG BATT POSITIVE VOLT DIMMING CONTROL
BCM 1 FUSE
BLK WIRE
BLK/WHT WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
COMPUTER DATA LINES SYSTEM
DIMMING CTRL
DK BLU WIRE
DK GRN WIRE
DOME LAMP SWITCH
FUEL ECONOMY MODE SWITCH FUEL ECONOMY MODE SWITCH (NOT USED)
GMLAN SERIAL DATA
HEAD
HORN SWITCH
HOT AT ALL TIMES
HOT W/ ACCESSORY RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMER SWITCH
INSTRUMENT PANEL FUSE BLOCK (RIGHT CENTER OF DASH)
INSTRUMENT STR PANEL WHL DM FUSE BLOCK FUSE (RIGHT CENTER OF DASH)
INTERIOR LIFTGATE CONTROL SWITCH (W/ POWER LIFT BODY EQUIPMENT)
LEFT STEERING WHEEL CONTROLS SWITCH
LOGIC
LT BLU WIRE
NCA WIRE
OFF AUTO PARK
RADIO/HVAC CONTROLS
RED/BLK WIRE
RED/WHT WIRE
RIGHT STEERING WHEEL CONTROLS SWITCH
RPRNDL FUSE
SERIAL DATA
STEERING WHEEL AIR BAG COIL (STEERING COLUMN)
SUNROOF SWITCH (W/ POWER SLIDING GLASS SUNROOF)
SUNROOF TILT SWITCH (W/ POWER SLIDING GLASS SUNROOF)
TRACTION CONTROL SWITCH
TRANSMISSION SHIFT LEVER POSITION INDICATOR
TURN SIGNAL/ MULTI-FUNCTION SWITCH
W/ POWER SLIDING GLASS SUNROOF, POWER LIFT BODY EQUIPMENT
W/ W/O CONTROL CONTROL STEERING STEERING WHEEL WHEEL
YEL WIRE
Go to component -> Instrument illumination circuit -> 9 1 8 DIMMER SW SIG BATT POSITIVE VOLT DIMMING CONTROL
