Chevrolet Equinox II (2009-2015) 59 42 low spd high spd Wiring diagrams
This page contains all the electrical diagrams for the component. 59 42 low spd high spd, in which he is found in the car Chevrolet Equinox II (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 59 42 low spd high spd (1 of 2)
39 40 DATA BUS + DATA BUS -
59 42 LOW SPD HIGH SPD
8 24 ECT SENS SIG LOW REF
BLK WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MOTOR (RIGHT FRONT OF ENGINE COMPT, BEHIND RADIATOR)
COOLING FAN RESISTOR (REAR OF COOLING FAN SHROUD)
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> 2.4l vin k, cooling fan circuit -> 59 42 LOW SPD HIGH SPD
Wiring diagram 59 42 low spd high spd (2 of 2)
39 40 DATA BUS + DATA BUS -
59 42 LOW SPD HIGH SPD
8 24 ECT SENS SIG LOW REF
BLK WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN SPEED CONTROL RELAY
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
GRY WIRE
HOT AT ALL TIMES
LEFT COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LT BLU WIRE
RIGHT COOLING FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
TAN WIRE
TAN/BLK WIRE
WHT WIRE
YEL WIRE
Go to component -> 3.6l vin 3, cooling fan circuit -> 59 42 LOW SPD HIGH SPD
