Chevrolet Equinox II (2009-2015) 39 40 data bus + data bus - Wiring diagrams
This page contains all the electrical diagrams for the component. 39 40 data bus + data bus -, in which he is found in the car Chevrolet Equinox II (2009-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 39 40 data bus + data bus - (1 of 4)
39 40 DATA BUS + DATA BUS -
59 42 LOW SPD HIGH SPD
8 24 ECT SENS SIG LOW REF
BLK WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MOTOR (RIGHT FRONT OF ENGINE COMPT, BEHIND RADIATOR)
COOLING FAN RESISTOR (REAR OF COOLING FAN SHROUD)
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
GRY WIRE
HOT AT ALL TIMES
LT BLU WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
YEL WIRE
Go to component -> 2.4l vin k, cooling fan circuit -> 39 40 DATA BUS + DATA BUS -
Wiring diagram 39 40 data bus + data bus - (2 of 4)
39 40 DATA BUS + DATA BUS -
59 42 LOW SPD HIGH SPD
8 24 ECT SENS SIG LOW REF
BLK WIRE
COMPUTER DATA LINES SYSTEM
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN SPEED CONTROL RELAY
DK BLU WIRE
DK GRN WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
GRY WIRE
HOT AT ALL TIMES
LEFT COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LT BLU WIRE
RIGHT COOLING FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
TAN WIRE
TAN/BLK WIRE
WHT WIRE
YEL WIRE
Go to component -> 3.6l vin 3, cooling fan circuit -> 39 40 DATA BUS + DATA BUS -
Wiring diagram 39 40 data bus + data bus - (3 of 4)
2500 2501 COMPUTER DATA LINES SYSTEM
39 40 DATA BUS + DATA BUS -
410 2761 (OR 476)
42 59 HIGH SPD LOW SPD
8 24 ECT SENS SIG LOW REF
A/C CMPRSR FUSE
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
A/C COMPRESSOR SOLENOID VALVE
BATT POS VOL
BLK WIRE
BLK/WHT WIRE
BLOWER MOTOR (LOWER RIGHT SIDE OF DASH)
BLOWER MOTOR CONTROL MODULE (ON BLOWER MOTOR)
BLOWER MTR SPD CTRL
BLOWER MTR SPLY VOL
BRN WIRE
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MOTOR (RIGHT FRONT OF ENGINE COMPT, BEHIND RADIATOR)
COOLING FAN RESISTOR (REAR OF COOLING FAN SHROUD)
COOLING FAN SPEED CONTROL RELAY (3.6L)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
GRY WIRE
GRY/BLK WIRE
HOT AT ALL TIMES
LEFT COOLING FAN MOTOR (BEHIND LEFT SIDE OF RADIATOR)
LOW REF
LOW REF SENS SIG RLY CTRL
LT BLU WIRE
ORG/ WIRE
ORG/BLK WIRE
PPL
RED WIRE
RED/BLK WIRE
RIGHT COOLING FAN MOTOR (BEHIND RIGHT SIDE OF RADIATOR)
TAN WIRE
TAN/BLK WIRE
WHT WIRE
YEL WIRE
Go to component -> Automatic a/c circuit (2 of 2) -> 39 40 DATA BUS + DATA BUS -
Wiring diagram 39 40 data bus + data bus - (4 of 4)
2500 2501 COMPUTER DATA LINES SYSTEM
39 40 DATA BUS + DATA BUS -
410 2761 (OR 476)
42 59 HIGH SPD LOW SPD
8 24 ECT SENS SIG LOW REF
A/C CMPRSR FUSE
A/C COMPRESSOR CLUTCH
A/C COMPRESSOR CLUTCH RELAY
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COOL FAN 1 FUSE
COOL FAN 2 FUSE
COOLING FAN HIGH SPEED RELAY
COOLING FAN LOW SPEED RELAY
COOLING FAN MOTOR (RIGHT FRONT OF ENGINE COMPT, BEHIND RADIATOR)
COOLING FAN RESISTOR (REAR OF COOLING FAN SHROUD)
COOLING FAN SPEED CONTROL RELAY (3.6L)
DK BLU WIRE
DK GRN WIRE
DK GRN/WHT WIRE
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE CONTROLS IGNITION RELAY
GRY WIRE
HOT AT ALL TIMES
LOW REF SENS SIG RLY CTRL
LT BLU WIRE
LT GRN WIRE
MODE DOOR ACTUATOR (LEFT SIDE OF HVAC MODULE)
ORG/BLK WIRE
PPL
RED WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
WHT WIRE
YEL WIRE
Go to component -> Manual a/c circuit (2 of 2) -> 39 40 DATA BUS + DATA BUS -
