Chevrolet Equinox II (2009-2015) 24 23 7 13 ser data bus+ ser data bus- sens sig 5-volt ref Wiring diagram
This page shows the only wiring diagram for the component.24 23 7 13 ser data bus+ ser data bus- sens sig 5-volt ref, which is found in the car Chevrolet Equinox II (2009-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 24 23 7 13 ser data bus+ ser data bus- sens sig 5-volt ref (1 of 1)
2.4L
2.4L CONTROL SOLENOID VALVE ASSEMBLY
24 23 7 13 SER DATA BUS+ SER DATA BUS- SENS SIG 5-VOLT REF
3.6L
39 40 48 68 47 DATA BUS (+) DATA BUS (-) SENS SIG LOW REF 5 VOLT REF
A/T SHIFT LOCK SOL SPLY VOL
AUTOMATIC TRANSMISSION ASSEMBLY
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (LOWER LEFT SIDE OF DASH)
BRAKE PEDAL POSITION SENSOR (TOP OF BRAKE PEDAL ASSEMBLY)
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DK GRN WIRE
GRY (OR BLK) WIRE
GRY WIRE
HOT AT ALL TIMES
LOW REF
RED/WHT WIRE
RVC BATT SNSR FUSE
START SIG
TAN WIRE
TAN/BLK WIRE
TAN/WHT WIRE
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION INTERNAL MODE SWITCH (IMS)
TRANSMISSION SHIFT LEVER
TRANSMISSION SHIFT LOCK CONTROL SOLENOID ACTUATOR
UNDERHOOD FUSE BLOCK (LEFT REAR OF ENGINE COMPT)
WHT (OR BLU) WIRE
WHT WIRE
YEL WIRE
Go to component -> Shift interlock circuit -> 24 23 7 13 SER DATA BUS+ SER DATA BUS- SENS SIG 5-VOLT REF
