Car Wiring Diagrams for Defoggers circuit for Chevrolet Equinox I (2004-2009)

BATTERY VOLTAGE BLK WIRE BLK/WHT WIRE COMPUTER DATA LINES SYSTEM DEFOGGER INDICATOR DK GRN WIRE GROUND HOT AT ALL TIMES HVAC CONTROL MODULE (AT CENTER OF DASH) HVAC/RFA FUSE 15 I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LOGIC PPL REAR DEFOG RELAY REAR DEFOGGER GRID REAR DEFOGGER SWITCH RED WIRE RED/WHT WIRE RELAY CONTROL RR DEFOG FUSE 48 SERIAL DATA UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE
