Chevrolet Equinox I (2004-2009) right right front park/ turn signal lamp front turn signal lamp wiring diagram
This page shows the only wiring diagram for the component.right right front park/ turn signal lamp front turn signal lamp, which is found in the car Chevrolet Equinox I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right right front park/ turn signal lamp front turn signal lamp wiring diagram (1 of 1)
BATT MAIN 1 FUSE 57
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE PEDAL POSITION SENSOR (ON BRAKE PEDAL ASSEMBLY)
BRN WIRE
CHEVROLET
CHEVROLET PONTIAC
CLSTR FUSE 18
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK BLU/WHT WIRE
DK GRN WIRE
FROM PARK LAMP PCB RELAY (UNDERHOOD FUSE BLOCK) (DIAGRAM 1 OF 2)
GRND
GRND MINOR
GRY WIRE
HAZARD SWITCH
HOT AT ALL TIMES
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
INSTRUMENT PANEL CLUSTER (IPC)
LEFT LICENSE LAMP
LEFT TURN IND
LOGIC
LT BLU WIRE
LT LT
ORG/ WIRE
ORG/BLK WIRE
PONTIAC
PRK LAMP/ TRLR FUSE 35
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RIGHT FRONT MARKER LAMP
RIGHT FRONT PARK LAMP
RIGHT LICENSE LAMP
RIGHT REAR MARKER LAMP
RIGHT REAR PARK/ MAJOR
RIGHT REAR PARK/ STOP LAMP MAJOR
RIGHT RIGHT FRONT PARK/ TURN SIGNAL LAMP FRONT TURN SIGNAL LAMP
RIGHT TURN IND
RT PRK LAMP FUSE 12
SERIAL DATA
STOP LAMP FUSE 27
STOP LAMP PCB RELAY
TAN WIRE
TRAILER TOW CIRCUIT
TURN SIGNAL LAMP MINOR GRND
WHT WIRE
Go to component -> Exterior lamps circuit (2 of 2) -> RIGHT RIGHT FRONT PARK/ TURN SIGNAL LAMP FRONT TURN SIGNAL LAMP
