Chevrolet Equinox I (2004-2009) recirculation door ctrl a air temp door ctrl a low ref low ref Wiring diagram

AIR BAG DISPLY AIR TEMP DOOR POS SIG AIR TEMPERATURE ACTUATOR (IN HVAC ASSEMBLY) AMBIENT AIR TEMPERATURE SENSOR (BEHIND FRONT GRILLE) BLK WIRE BLK/WHT WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DK BLU WIRE DK GRN WIRE EVAPORATOR TEMPERATURE SENSOR (ON LEFT SIDE OF HVAC MODULE ASSEMBLY) FUSE GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HOT W/ IGN 1 RELAY ENERGIZED HVAC CONTROL MODULE (AT CENTER OF DASH) HVAC/ BLWR LOW REF LT BLU WIRE LT DK LT GRN WIRE LT GRN/BLK WIRE MODE DOOR CTRL A PNK WIRE POWER DISTRIBUTION SYSTEM PPL PPL/WHT WIRE REAR DEFOG CTRL RLY OUTSIDE AIR TEMP SENS SIG GND RECIRCULATION DOOR CTRL A AIR TEMP DOOR CTRL A LOW REF LOW REF RECIRCULATION DOOR CTRL B AIR TEMP DOOR CTRL B RED WIRE RED/BLK WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPT) WHT WIRE YEL WIRE
