Chevrolet Equinox I (2004-2009) express sig low ref open sig open vent sig soft stop sig Wiring diagram
This page shows the only wiring diagram for the component.express sig low ref open sig open vent sig soft stop sig, which is found in the car Chevrolet Equinox I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram express sig low ref open sig open vent sig soft stop sig (1 of 1)
1 2 3 4 5 6 7 8 LOW REF
ACC VOLT LOW REF MTR OPEN CTRL
BLK WIRE
BRN WIRE
CLOSE
DK BLU WIRE
DK GRN WIRE
EXPRESS
EXPRESS SIG LOW REF OPEN SIG OPEN VENT SIG SOFT STOP SIG
GROUND
HOT W/ RAP PCB RELAY ENERGIZED
I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO)
LIMIT SWITCH
LT GRN WIRE
ORG/ WIRE
ORG/BLK WIRE
S/ROOF FUSE 1
SLIDE
SUNROOF CONTROL MODULE (RIGHT REAR OF SUNROOF MODULE ASSEMBLY)
SUNROOF MOTOR (AT RIGHT REAR OF SUNROOF MODULE ASSEMBLY)
SUNROOF SWITCH
VENT OPEN
YEL WIRE
