Chevrolet Equinox I (2004-2009) data enable batt pos vol Wiring diagram
This page shows the only wiring diagram for the component.data enable batt pos vol, which is found in the car Chevrolet Equinox I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram data enable batt pos vol (1 of 1)
AWD COIL/ TEMPERATURE SENSOR (INSIDE FRONT COVER OF REAR DIFFERENTIAL)
AWD FUSE 41
BLK WIRE
COMPUTER DATA LINES SYSTEM
DATA ENABLE BATT POS VOL
HI DATA BUS- HI DATA BUS+
HOT AT ALL TIMES
LOW REF LOW REF AWD SENS SIG AWD SUP VOL
LT BLU WIRE
RED WIRE
RED/WHT WIRE
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT)
WHT WIRE
YEL WIRE
Go to component -> Rear differential lock circuit -> DATA ENABLE BATT POS VOL
