Chevrolet Equinox I (2004-2009) 16 17 13 15 14 ser data bus+ ser data bus- br ped pos sen sig Wiring diagram
This page shows the only wiring diagram for the component.16 17 13 15 14 ser data bus+ ser data bus- br ped pos sen sig, which is found in the car Chevrolet Equinox I (2004-2009). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 16 17 13 15 14 ser data bus+ ser data bus- br ped pos sen sig (1 of 1)
16 17 13 15 14 SER DATA BUS+ SER DATA BUS- BR PED POS SEN SIG
A/T ST LK CNTRL SUP VOT
BAT POS VOT
BLK WIRE
BRAKE PEDAL POSITION SENSOR (ON BRAKE PEDAL ASSEMBLY)
COMPUTER DATA LINES SYSTEM
DK BLU WIRE
DK GRN/WHT WIRE
GRY WIRE
HOT AT ALL TIMES
LOW REF
ORG/BLK WIRE
RED/WHT WIRE
RVC FUSE (LEFT SIDE OF ENGINE COMPT)
TAN WIRE
TAN/BLK WIRE
UNDERHOOD FUSE BLOCK
Go to component -> Shift interlock circuit -> 16 17 13 15 14 SER DATA BUS+ SER DATA BUS- BR PED POS SEN SIG
