Chevrolet Equinox I (2004-2009) 1 2 3 4 5 6 7 8 batt pos volt ground Wiring diagram

1 2 3 4 5 6 7 8 BATT POS VOLT GROUND BLK WIRE COMPUTER DATA LINES SYSTEM DK BLU WIRE DK GRN WIRE DRIVER HEATED NTC SIG DRIVER HEATED SEAT BACK ELEMENT (IN DRIVER SEAT BACK) DRIVER HEATED SEAT CUSHION ELEMENT (IN DRIVER SEAT CUSHION) DRIVER HEATED SEAT SWITCH DRIVER HEATED SPLY FRONT PASSENGER HEATED SEAT BACK ELEMENT (IN FRONT PASSENGER SEAT BACK) FRONT PASSENGER HEATED SEAT CUSHION ELEMENT (IN FRONT PASSENGER SEAT CUSHION) GRY WIRE HEATED SEAT CONTROL MODULE (UNDER RIGHT FRONT SEAT) HIGH HEAT IND HOT AT ALL TIMES HTD SEATS FUSE 6 HVAC CONTROL MODULE (AT CENTER OF DASH) I/P FUSE BLOCK (CENTER OF DASH, BENEATH RIGHT SIDE OF RADIO) LOGIC LOW HEAT IND LOW REF LOW SPEED GMLAN SERIAL DATA LT BLU WIRE ORG/ WIRE PNK TEMP SEN SIG WIRE PNK WIRE PPL PPL LOW REF RED WIRE RED/WHT WIRE TAN WIRE WHT WIRE YEL WIRE YEL/BLK WIRE
