Chevrolet Cutaway P30 (1985-1997) glow plug controller and relay Wiring diagram
This page shows the only wiring diagram for the component.glow plug controller and relay, which is found in the car Chevrolet Cutaway P30 (1985-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram glow plug controller and relay (1 of 1)
6.5L VIN F
6.5L VIN F 7.4L VIN J
7.4L VIN J (L29), 6.5L VIN F (L65) ENGINES ONLY
7.4L VIN N
A/C COMPRESSOR CONTROL RELAY
AUDIO ALARM
AUXILIARY FAN CONTROL RELAY
BATTERY
BATTERY JUNCTION BLOCK (ON FORWARD LEFT SIDE OF THE BULKHEAD)
BLANK FUSE
BLK WIRE
BUSS BAR
DATA LINK CONNECTOR (DLC)
DIESEL
DOME LAMP
ELECTRONIC BRAKE CONTROL MODULE
ENG-BAT FUSE
FUEL PUMP RELAY
FUEL PUMP SWITCH AND OIL PRESSURE GAUGE
FUSIBLE LINK
FUSIBLE LINK (10 GA-
FUSIBLE LINK (10 GA-RUST)
FUSIBLE LINK (14 GA-
FUSIBLE LINK (16 GA-
FUSIBLE LINK 12 GA. BLUE
FUSIBLE LINK 18 GA. BLUE
GENERATOR (ON RIGHT FRONT OF ENGINE)
GLOW PLUG CONTROLLER AND RELAY
GRY WIRE
HAZARD FLASHER
HEADLAMPS SWITCH
HORN RELAY
HORN- DM FUSE
I/P FUSE BLOCK (MOUNTED ON THE I/P)
IGNITION SWITCH (DIAGRAM 2 OF 4)
ONLY
ORG/ WIRE
PARK BRAKE PUMP RELAY
POWERTRAIN CONTROL MODULE (PCM)
POWERTRAIN CONTROL MODULE (PCM) VEHICLE CONTROL MODULE (VCM)
PWR CIRCUIT BREAKER
RED WIRE
SECONDARY BATTERY (DIESEL ONLY)
STARTER MOTOR (ON RIGHT REAR SIDE OF ENGINE)
STARTER RELAY
STOP- HAZ FUSE ECM- BAT FUSE
STOPLAMP SWITCH
TAIL LAMPS FUSE
Go to component -> Power distribution circuit, motor home chassis (1 of 4) -> GLOW PLUG CONTROLLER AND RELAY
