6.0l vin u, a/t circuit for Chevrolet Cutaway G3500 (1997-2012)

1 2 6 8 20 21 22 23 40 42 47 48 51 62 63 GND TCC PWM CTRL PC SOL HI CTRL AUTOMATIC TRANSMISSION INPUT SHAFT SPEED SENSOR BLK WIRE BLK/WHT WIRE BRN WIRE DK BLU WIRE DK BLU/WHT WIRE DK GRN WIRE ENGINE COOLANT TEMPERATURE SENSOR (ON LEFT SIDE OF ENGINE) FROM UNDERHOOD PASS- THROUGH GROMMET BREAKOUT) GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ACCY, RUN, START HOT IN RUN, START IGN 0 FUSE 6 INSTRUMENT PANEL CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PARK/NEUTRAL POSITION SWITCH (LEFT SIDE OF TRANSMISSION) PC SOL LO CTRL PPL FRONT LOW SIG FRONT HIGH SIG PCM BATT FUSE 2 PCM IGN 1 FUSE 38 PNK WIRE POWERTRAIN CONTROL MODULE (IN ENGINE COMPT, ON LEFT INNER FENDER) PPL PRNDL INDICATOR RED/WHT WIRE SERIAL DATA TAN WIRE TAN/BLK WIRE TAN/WHT WIRE TOW/ HAUL SWITCH TOW/HAUL INDICATOR TOW/HAUL SWITCH SIG UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) VEHICLE SPEED SENSOR WHT WIRE YEL WIRE YEL/BLK WIRE

1-2 SOL 2-3 SOL 3-2 SOL A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH AUTOMATIC TRANSMISSION BLK WIRE BLU WIRE BRN WIRE DK BLU WIRE GRY WIRE HOT IN RUN, START IGN E FUSE 22 LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE ORG/ WIRE ORG/BLK WIRE PC SOL VALVE PNK WIRE PPL RED WIRE REV STOP LAMP SWITCH (ABOVE BRAKE PEDAL) TAN (OR BLK) WIRE TAN WIRE TAN/BLK WIRE TCC PWM SOL TCC SOL TFT SENSOR UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK (LEFT SIDE OF ENGINE COMPARTMENT) WHT WIRE YEL WIRE YEL/BLK WIRE
