5.7l vin r, a/t circuit, 4l80-e for Chevrolet Cutaway G3500 (1997-2012)

1225 1224 PNK WIRE 2-3 SS 29 30 VSS LO (GROUND) VSS HI (SIGNAL) 3-2 SS A/T FLUID PRESSURE MANUAL VALVE POSITION SWITCH ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES SYSTEM (ELECTRONIC BRAKE CONTROL MODULE) AUTOMATIC TRANSMISSION AUTOMATIC TRANSMISSION INPUT SHAFT SPEED SENSOR (ON LEFT SIDE OF TRANSMISSION) BLK WIRE BLK/WHT WIRE BRAKE FUSE 18 BRN WIRE BRN/WHT WIRE CRUISE CONTROL SYSTEM DATA LINK CONNECTOR (DLC) (PARTIAL) (UNDER LEFT SIDE OF DASH) DK BLU WIRE DK BLU/WHT WIRE ECM-B FUSE ENGINE CONTROLS SYSTEM ENGINE CONTROLS SYSTEM (FUEL INJECTORS) ENGINE CONTROLS SYSTEM (FUEL PUMP RELAY) ENGINE COOLANT TEMPERATURE (ECT) SENSOR (ON TOP FRONT OF ENGINE) GAUGES FUSE 4 GRY WIRE HOT AT ALL TIMES HOT IN HOT IN OFF, RUN OR START HOT IN RUN OR START I/P FUSE BLOCK (ON LEFT LOWER KICK PANEL) INSTRUMENT CLUSTER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/BLK WIRE MALFUNCTION INDICATOR LAMP ORG/ WIRE PNK PNK WIRE PNK WIRE PPL PPL/WHT WIRE PRESSURE CONTROL SOLENOID VALVE RED WIRE RED/BLK WIRE RUN WIRE TAN/WHT WIRE TCC PWM SOL TCC/ABS/ CRUISE SWITCH TCC/STOPLAMP SWITCH (BEHIND DASH, ON BRAKE PEDAL SUPPORT) THROTTLE POSITION (TP) SENSOR (ON SIDE OF THROTTLE BODY) TRANS FLUID TEMP SENSOR TRANS FUSE 20 UNDERHOOD FUSE/RELAY CENTER (ON LEFT SIDE OF ENGINE COMPT) ECM-I FUSE VEHICLE CONTROL MODULE (VCM) (ON LEFT SIDE OF ENGINE COMPT) VEHICLE SPEED SENSOR (VSS) (ON LEFT SIDE OF TRANSMISSION) YEL WIRE YEL/BLK WIRE
