6.0l vin g, charging circuit for Chevrolet Cutaway G3500 (1997-2012)

27 28 2501 2500 44 43 COMPUTER DATA LINES SYSTEM DATA BUS (-) DATA BUS (+) 4.3L 4.3L/5.3L 4.8L/6.0L BATTERY BATTERY CURRENT SENSOR (4.3L/5.3L) BLK WIRE BODY CONTROL MODULE (BCM) (BEHIND LOWER RIGHT SIDE OF DASH) BRN WIRE CHARGE IND COMPUTER DATA LINES SYSTEM CURRENT SENSOR SIG DK GRN WIRE DRIVER INFORMATION CENTER (DIC) DISPLAY ENGINE CONTROL MODULE (ECM) (LEFT SIDE OF ENGINE COMPT) EXCEPT 4.3L FUSIBLE LINK 3 GENERATOR GENERATOR FIELD DUTY CYCLE SIG GENERATOR TURN ON SIG GMLAN SERIAL DATA GRY WIRE HOT W/ RUN/CRANK RELAY 15 ENERGIZED IPC FUSE 10 IGN VOLT INSTRUMENT PANEL CLUSTER (IPC) LOGIC LOW REF LOW SPEED GMLAN SERIAL DATA PNK WIRE ORG/ WIRE PNK WIRE POWER DISTRIBUTION SYSTEM RED WIRE SENS SIG STARTING CIRCUIT TAN WIRE TAN/BLK WIRE UNDERHOOD FUSE BLOCK (ON LEFT SIDE OF ENGINE COMPT) WHT WIRE
