Chevrolet Cutaway G30 (1985-1994) Charging circuit, cutaway chassis

BAT VOLT SENSE INPUT BATTERY BATTERY JUNCTION BLOCK BLK WIRE BLK/RED WIRE FUSE BLOCK FUSIBLE LINK (10 GA-RUST) GAGES FUSE GENERATOR (NOT USED) (RIGHT FRONT OF ENGINE) HOT IN RUN OR START INSTRUMENT CLUSTER PNK/BLK WIRE RECTIFIER BRIDGE RED WIRE REGULATOR (SOLID STATE) STARTER CIRCUIT STATOR SW BAT FIELD (ROTOR) TURN ON INPUT VOLT- METER
