Chevrolet Cruze II (2015-2024) rear seat heating control module fuse Wiring diagram
This page shows the only wiring diagram for the component.rear seat heating control module fuse, which is found in the car Chevrolet Cruze II (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear seat heating control module fuse (1 of 1)
1.6L TURBO DIESEL
1.6L TURBO DIESEL 1.4L TURBO 6-SPEED, 9-SPEED A/T
6 SPEED A/T
A/C COMPRESSOR CLUTCH RELAY
A/T
ACCESSORY DC/AC POWER INVERTER MODULE
ACCESSORY DC/AC POWER INVERTER MODULE FUSE
AEROSHUTTER FUSE
AFL/AHL POWER 1 MOTOR LAMPS LH FUSE
AFL/AHL POWER 2 MOTOR LAMPS LH FUSE
AIR- CONDITION FUSE
ANTI-LOCK BRAKING SYSTEM FUSE
BLK WIRE
BLU WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
CLUSTER FUSE
COLLISION ALERT INDICATORS
COOLING FAN MOTOR
CTRL
DIESEL FUEL HEATING/ SECONDARY AIR INDUCTION FUSE
ELECTRICAL AUXILIARY HEATER
ELECTRONIC BRAKE CONTROL MODULE
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE FUSE
ENGINE/ TRANSMISSION CONTROL MODULE FUSE
ESCL FUSE
FROM BATTERY FUSE BLOCK (DIAGRAM 1 OF 5)
FROM INSTRUMENT PANEL FUSE BLOCK (DIAGRAM 2 OF 5)
FRONT FOG LAMP RELAY
FUEL HEATER RELAY
FUEL HEATER/ WATER IN FUEL SENSOR
FUEL PUMP DRIVER CONTROL
FUEL PUMP DRIVER CONTROL MODULE
FUEL PUMP FUSE
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
GENERATOR
GRN/VIO WIRE
GRY WIRE
HATCHBACK
HEADLAMP HIGH BEAM RELAY
HORN RELAY
HVAC CONTROL MODULE
IGNITION MAIN RELAY
INSIDE REAR VIEW MIRROR
INSIDE REAR VIEW MIRROR/ REAR VIEW CAMERA/ TRAILER FUSE
INSTRUMENT CLUSTER
INVERTER
LOGIC
M/T
NCA WIRE
ORG/ WIRE
PHASE A
PHASE B
PNK WIRE
POWER STEERING CONTROL MODULE
POWER SUPPLY TRANSFORMER
REAR DEFOGGER RELAY
REAR SEAT HEATING CONTROL MODULE
REAR SEAT HEATING CONTROL MODULE FUSE
REAR VIEW CAMERA
REAR WINDOW WASHER PUMP RELAY
REAR WIPER FUSE
REAR WIPER RELAY
RED WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/VIO WIRE
RED/YEL WIRE
SEDAN
STARTER 1 FUSE
STARTER 2 FUSE
STARTER MOTOR
STARTER PINION SOLENOID ACTUATOR RELAY
STARTER RELAY
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATING CONTROL MODULE
SWITCHABLE WATER PUMP/ WATER IN FUEL SENSOR FUSE
TO DIESEL NOX FUSE (DIAGRAM 2 OF 5)
TRANSMISSION CONTROL MODULE
UNDERHOOD FUSE BLOCK
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
VIO/WHT WIRE
W/ STOP/ START SYSTEM
WINDSHIELD WASHER PUMP RELAY
WINDSHIELD WASHER/ REAR WINDOW FUSE
WINDSHIELD WIPER FUSE
WINDSHIELD WIPER MOTOR MODULE
Go to component -> Power distribution circuit (3 of 5) -> REAR SEAT HEATING CONTROL MODULE FUSE
