Chevrolet Cruze II (2015-2024) ign mode sw feed Wiring diagram
This page shows the only wiring diagram for the component.ign mode sw feed, which is found in the car Chevrolet Cruze II (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram ign mode sw feed (1 of 1)
1.6L TURBO DIESEL 1.4L TURBO
ACC WAKEUP SER DATA
AUTOMATIC TRANSMISSION ASSEMBLY
BATT POS VOLT
BATTERY FUSE BLOCK
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BLU/BLK WIRE
BLU/ORG WIRE
BODY CONTROL MODULE (UNDER LEFT SIDE OF INSTRUMENT PANEL)
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
FUSE 5
FUSE 6
GRN WIRE
GRN/GRY WIRE
HATCHBACK
HI SPD GMLAN (-) 1
HI SPD GMLAN (-) 1 IGN MODE SW
HI SPD GMLAN SER DATA (+) 3
HOT AT ALL TIMES
IGN 1 VOLT
IGN MODE SW FEED
IGN MODE SW RTN
IGN RES SIG
IGN VOLT
IGNITION MODE SWITCH
KEYLESS ENTRY CONTROL MODULE
LOW SPEED GMLAN
P/N TRANS SIG 1
PINION SOL RLY CTRL
POWER DISTRIBUTION SYSTEM
POWER SUPPLY TRANSFORMER
RED/GRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RUN/CRANK IGN 1 VOLT
STARTER RLY CTRL
STRTR RLY COIL CTRL
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
VIO/GRN WIRE
VIO/GRY WIRE
VIO/YEL WIRE
W/ KEYLESS ENGINE START SWITCH
WHT WIRE
WHT/GRY WIRE
WHT/ORG WIRE
YEL/BLK WIRE
YEL/VIO WIRE
Go to component -> Starting circuit (2 of 2) -> IGN MODE SW FEED
