Chevrolet Cruze II (2015-2024) gnd lin serial data bus 12 Wiring diagram
This page shows the only wiring diagram for the component.gnd lin serial data bus 12, which is found in the car Chevrolet Cruze II (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram gnd lin serial data bus 12 (1 of 1)
"CHECK ENGINE" IND CTRL
ABS IND.
AIR BAG IND
BATT POS VOLT
BLK WIRE
BLK/WHT WIRE
BRAKE WARNING IND
BRN WIRE
BRN/WHT WIRE
CHARGING IND
CLUSTER FUSE
COMPUTER DATA LINES SYSTEM
CRUISE IND
DISPLAY
DISPLAY DIMMING CTRL
DOOR AJAR IND
DRIVER INFORMATION CENTER DISPLAY
DRL IND
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE
ENGINE OIL LEVEL GAUGE
ENGINE OIL LEVEL IND
ENGINE OIL PRESSURE IND
ESC IND
ESC OFF IND
FRONT FOG LAMP IND
FUEL GAUGE
FUSE 25
FUSE 36
GLOW PLUG IND
GND LIN SERIAL DATA BUS 12
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/GRN WIRE
GRY/YEL WIRE
HAZARD SWITCH
HIGH BEAM ASSIST IND
HIGH BEAM LAMP IND
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGNITION 1 VOLT
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LED CTRL
LEFT TURN
LEFT TURN SIG IND
LOGIC
LOW FUEL IND
LOW REF
LOW SPEED GMLAN SERIAL DATA 2
MALFUNCTION IND
MENU
MENU SW SIG
NAVIGATION SYSTEM
PARK LAMP IND
PARKING ASSIST IND
POWER STEERING WARNING LIGHT IND
RED/BLU WIRE
RED/YEL WIRE
RIGHT STEERING WHEEL CONTROLS SWITCH
RIGHT TURN
RIGHT TURN SIG IND
SEAT BELT IND
SECURITY IND
SELECT LOGIC
SET-
SPEEDOMETER
STAR IND CTRL
STEERING WHEEL AIR BAG COIL
SW SIG
TACHOMETER
TIRE PRESSURE IND
TRACTION CONTROL OFF IND
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
VIO/BRN WIRE
VIO/GRN WIRE
W/ STEERING WHEEL CONTROLS W/O STEERING WHEEL CONTROLS
WHT/GRN WIRE
WHT/ORG WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> GND LIN SERIAL DATA BUS 12
