Chevrolet Cruze II (2015-2024) closure handle sw open sig Wiring diagram
This page shows the only wiring diagram for the component.closure handle sw open sig, which is found in the car Chevrolet Cruze II (2015-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram closure handle sw open sig (1 of 1)
ACCESSORY WAKEUP SER DATA
ACTIVE SIG
ANTI-LOCK BRAKES, CRUISE CONTROL SYSTEMS
BACKUP LP CTRL
BATT POSITIVE VOLT
BATTERY POSITIVE VOLT
BLK WIRE
BLU WIRE
BLU/BRN WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BODY CONTROL MODULE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLOSURE HANDLE SW OPEN SIG
COMPUTER DATA LINES SYSTEM
COURTESY LAMP
CRUISE/ETC/TCC BRAKE SIG
DOOR LOCK SW LOCK CTRL
DOOR LOCKS SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
DR LK ACTUATOR UNLK CTRL
DR LK CTRL
DRV DR LK ACTUATOR
DRV SW LOCK CTRL
FOG LP RLY CTRL
FUSE 15
FUSE 16
FUSE 17
GMLAN SER DATA - (1)
GRN WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/BRN WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HDLP HI BEAM RLY CTRL
HEADLIGHTS SYSTEM
HOOD AJAR SW SIG
HORN RLY CTRL
HORNS SYSTEM
HOT AT ALL TIMES
INADVERTENT PWR CTRL
INSTRUMENT PANEL FUSE BLOCK
INT LP CTRL
LED BACKLT DIMMING CTRL
LEFT HDLP LO BEAM CTRL
LEFT PARK LP CTRL
LF TURN SIG LP CTRL
LH PARK LP CTRL
LH PARK LP CTRL LR TURN SIG LP CTRL
LID LP CTRL
LIFT GATE AJAR SW SIG (1) DRV SW UNLOCK SIG
LO SPEED GMLAN SER DATA
LP DEFEAT SW SIG
LR STOP LP CTRL
NETWORK BUS 1
NETWORK BUS 2
NETWORK BUS 3
POWER DISTRIBUTION SYSTEM
RAP RELAY COIL CTRL
REAR COMPT LID INT RELEASE SIG
REAR LICENSE LP CTRL
RED WIRE
RED/BRN WIRE
RED/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
RF DRL CTRL
RF TURN SIG LP CTRL
RH PARK LAMP CTRL
RH PARK LP CTRL RR TURN SIG LP CTRL
RIGHT HDLP LO BEAM CTRL
RIGHT PARK LP CTRL
RR COMPT LID MTR RELEASE CTRL
RR STOP LP CTRL
RR WINDOW WASHER RLY CTRL
RR WIPER MTR RLY COIL CTRL
RUN/CRANK RLY COIL CTRL
SEDAN HATCHBACK
SER DATA COMM ENABLE
SHIFT INTERLOCK SOL CTRL
SHIFT INTERLOCK SYSTEM
SHIFT INTERLOCK SYSTEM INTERIOR LIGHTS SYSTEM
SHIFT POS SIG
STOP LP RLY COIL CTRL
SW UNLOCK CTRL
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO/BLU WIRE
VIO/GRY WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/ORG WIRE
WHT/YEL WIRE
WINDSHIELD WASHER RLY CTRL
WIPER MTR RLY COIL CTRL
WIPER/WASHER SYSTEM
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Body control modules circuit (2 of 2) -> CLOSURE HANDLE SW OPEN SIG
