Trunk release circuit for Chevrolet Cruze I facelift (2012-2015)
Trunk release circuit
BLK WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (UNDER CENTER DASH)
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
EXTERIOR REAR COMPARTMENT LID UNLATCH SWITCH
FUSE 16
FUSE 23
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT FUSE 23 END OF DASH)
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LIFT GATE AJAR SW SIG
LIFT GLASS/TRUNK MTR RELEASE CTRL
LO SPD GMLAN 22 1 SERIAL DATA
LO SPD GMLAN SERIAL DATA
LO SPD GMLAN SERIAL DATA B+ 22 1
LOGIC
REAR CLOSURE HNDL SW OPEN SIG
REAR COMPARTMENT LID LATCH
REAR COMPARTMENT LID UNLATCH RELAY
RED/BLU WIRE
RED/GRY WIRE
VIO/GRY WIRE
W/ REARVIEW CAMERA
W/ REARVIEW CAMERA W/O REARVIEW CAMERA
YEL/BLU WIRE
