Steering lock circuit for Chevrolet Cruze I facelift (2012-2015)
Steering lock circuit
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BODY CONTROL MODULE (BCM)
BODY CONTROL MODULE (BCM) (UNDER CENTER DASH)
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS, ANTI-THEFT SYSTEMS
FUSE 25
FUSE 57
FUSE FUSE BLOCK (BEHIND LEFT END OF DASH)
GMLAN SERIAL DATA
GRN WIRE
GRN/VIO WIRE
HOT AT ALL TIMES
HOT W/ IGNITION RUN RELAY ENERGIZED
INSTRUMENT PANEL
INSTRUMENT PANEL FUSE BLOCK
LOGIC
OFF/ACCESSORY VOLT
OFF/ACCESSORY VOLT STEERING COLUMN LK SIG +B GND GND GMLAN SERIAL DATA
RED WIRE
RED/BRN WIRE
STEERING COLUMN LK SIG
STEERING COLUMN LOCK MODULE (UNDER LEFT SIDE OF DASH)
STEERING COLUMN LOCK STATUS SIG
UNDERHOOD FUSE BLOCK
VIO WIRE
