Power windows circuit, w/o express up/down for Chevrolet Cruze I facelift (2012-2015)
Power windows circuit, w/o express up/down
AJAR SW
BLK WIRE
BLU/GRY WIRE
BLU/VIO WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DOWN
DRIVER WINDOW MOTOR
DRIVER WINDOW SWITCH
DRIVER'S DOOR
FUSE 21
FUSE 24
GRN/BLK WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GROUND
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT WINDOW SWITCH
LEFT REAR WINDOW MOTOR
LEFT REAR WINDOW SWITCH
LOCK OUT IND
LOCK OUT SWITCH
LOGIC
NETWORK BUS 3
PASSENGER WINDOW MOTOR
PASSENGER WINDOW SWITCH
RED/BRN WIRE
RED/GRN WIRE
RIGHT FRONT WINDOW SWITCH
RIGHT REAR DOOR
RIGHT REAR WINDOW MOTOR
RIGHT REAR WINDOW SWITCH
UNDERHOOD FUSE BLOCK
WHT/VIO WIRE
YEL/BLU WIRE
YEL/VIO WIRE
