Electrochromic mirror circuit for Chevrolet Cruze I facelift (2012-2015)
Electrochromic mirror circuit
BACKUP LP CTRL
BLK WIRE
BRN/WHT WIRE
CALL
EMERGENCY
EMERGENCY IND
FUSE 53
GRN/BLK WIRE
GRN/WHT WIRE
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN VOLT
INSIDE REARVIEW MIRROR
KEYPAD GREEN LED
KEYPAD GRN LED IND WIRE
KEYPAD RED LED IND WIRE
KEYPAD RED LED WIRE
KEYPAD SIG
KEYPAD SPLY VOLT
LOGIC
MIRROR DIMMING
ONSTAR
ONSTAR IND
PHONE IND
SIDE OF DASH)
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE
TELEMATICS COMMUNICATION INTERFACE CONTROL MODULE (BEHIND RIGHT
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
VIO/WHT WIRE
YEL/VIO WIRE
