Rear view camera circuit for Chevrolet Cruze I facelift (2012-2015)
Rear view camera circuit
5 15 CAMERA SIG - CAMERA SIG +
BACKUP LAMP CTRL
BACKUP LAMP SPLY VOLT
BARE
BARE (BLUNT CUT SHIELD)
BARE CAMERA SHIELD EXTENSION
BLK WIRE
BODY CONTROL MODULE
BODY CONTROL MODULE (UNDER CENTER DASH)
CAMERA SIG (-)
CAMERA SIG 2
FUSE
FUSE 54
GRN/WHT WIRE
GRN/YEL WIRE
GROUND
GRY/YEL WIRE
HOT W/ IGNITION MAIN RELAY ENERGIZED
POWER DISTRIBUTION SYSTEM
RADIO
REARVIEW CAMERA
RUN/CRANK IGN VOLT 1
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
VIO/BLK WIRE
VIO/WHT WIRE
WHT/BLU WIRE
