Chevrolet Cruze I facelift (2012-2015) transmission internal mode switch Wiring diagram
This page shows the only wiring diagram for the component.transmission internal mode switch, which is found in the car Chevrolet Cruze I facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission internal mode switch (1 of 1)
43 29 HIGH SPEED SERIAL DATA(-) HIGH SPEED SERIAL DATA(+)
AUTOMATIC TRANSMISSION ASSEMBLY
BATTERY
BATTERY CURRENT SENSOR
BATTERY FUSE BLOCK
BATTERY FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
BLK WIRE
BLK/GRY WIRE
BLU WIRE
BODY CONTROL MODULE (UNDER CENTER DASH)
CLUTCH PEDAL POSITION SENSOR
CLUTCH PEDAL POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL)
COMPUTER DATA LINES
COMPUTER DATA LINES SYSTEM
CONTROL SOLENOID VALVE ASSEMBLY
ENGINE CONTROL MODULE
ENGINE CONTROL MODULE (1.8L: LEFT SIDE OF ENGINE COMPT)
FUSE 12
FUSE 5
FUSE 6
GMLAN SERIAL DATA
GRN WIRE
GROUND DISTRIBUTION SYSTEM
GRY WIRE
GRY/RED WIRE
HIGH SPEED SERIAL DATA(+)
IGN KEY SIG
IGN VOLT
IGNITION SWITCH
LOW REF
OFF
PARK/NEUTRAL SW SIG
POWER DISTRIBUTION SYSTEM
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RUN WIRE
SENS SIG
SENS VOLT REF
STARTER ENABLE RELAY CTRL
STARTER MOTOR
STARTER RELAY
SYSTEM
TRANSMISSION CONTROL MODULE
TRANSMISSION INTERNAL MODE SWITCH
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
WHT WIRE
WHT/BLK WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Starting circuit -> TRANSMISSION INTERNAL MODE SWITCH
