Chevrolet Cruze I facelift (2012-2015) stack data low Wiring diagrams

This page contains all the electrical diagrams for the component. stack data low, in which he is found in the car Chevrolet Cruze I facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

stack data low wiring diagram (1 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (1 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY RESET SIG DISPLAY SIG + DRAIN WIRE ELECTRONIC BRAKE CONTROL MODULE ENABLE SIG FUSE 5 GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT W/ BATTERY SAVER RELAY 1 ENERGIZED INFO DISPLAY MODULE INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INSTRUMENT PANEL FUSE BLOCK LF SPD SENS SIG LO REF NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE VIO WIRE VOICE AUDIO SIG W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Navigation circuit, w/ amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (2 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (2 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 VOICE AUDIO SIG CAMERA SIG 2+ LO REF CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY SIG + DISPLAY SIG - LF SPD SENS SIG DRAIN WIRE DRAIN WIRE DISPLAY SIG + DISPLAY RESET SIG ELECTRONIC BRAKE CONTROL MODULE (W/ NAVIGATION) (NEAR BRAKE MASTER CYLINDER) ENABLE SIG FUSE 5 GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT W/ BATTERY SAVER RELAY 1 ENERGIZED INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INFO DISPLAY MODULE (W/O NAVIGATION) (IF EQUIPPED) (BEHIND CENTER OF DASH) INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH) NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE USB CABLE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 VIO WIRE W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Navigation circuit, with amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (3 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (3 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 VOICE AUDIO SIG CAMERA SIG 2+ LO REF CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY SIG + DISPLAY SIG - LF SPD SENS SIG DRAIN WIRE DRAIN WIRE DISPLAY SIG + DISPLAY RESET SIG ELECTRONIC BRAKE CONTROL MODULE (W/ NAVIGATION) (NEAR BRAKE MASTER CYLINDER) ENABLE SIG GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INFO DISPLAY MODULE (W/O NAVIGATION) (IF EQUIPPED) (BEHIND CENTER OF DASH) NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE USB CABLE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 VIO WIRE W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Navigation circuit, without amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (4 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (4 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY RESET SIG DISPLAY SIG + DRAIN WIRE ELECTRONIC BRAKE CONTROL MODULE ENABLE SIG FUSE 5 GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT W/ BATTERY SAVER RELAY 1 ENERGIZED INFO DISPLAY MODULE INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INSTRUMENT PANEL FUSE BLOCK LF SPD SENS SIG LO REF NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE VIO WIRE VOICE AUDIO SIG W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Navigation circuit, w/o amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (5 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (5 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY RESET SIG DISPLAY SIG + DRAIN WIRE ELECTRONIC BRAKE CONTROL MODULE ENABLE SIG FUSE 5 GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT W/ BATTERY SAVER RELAY 1 ENERGIZED INFO DISPLAY MODULE INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INSTRUMENT PANEL FUSE BLOCK LF SPD SENS SIG LO REF NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE VIO WIRE VOICE AUDIO SIG W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Radio circuit, w/ amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (6 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (6 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 VOICE AUDIO SIG CAMERA SIG 2+ LO REF CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY SIG + DISPLAY SIG - LF SPD SENS SIG DRAIN WIRE DRAIN WIRE DISPLAY SIG + DISPLAY RESET SIG ELECTRONIC BRAKE CONTROL MODULE (W/ NAVIGATION) (NEAR BRAKE MASTER CYLINDER) ENABLE SIG FUSE 5 GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT W/ BATTERY SAVER RELAY 1 ENERGIZED INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INFO DISPLAY MODULE (W/O NAVIGATION) (IF EQUIPPED) (BEHIND CENTER OF DASH) INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH) NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE USB CABLE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 VIO WIRE W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Radio circuit, with amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (7 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (7 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 VOICE AUDIO SIG CAMERA SIG 2+ LO REF CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY SIG + DISPLAY SIG - LF SPD SENS SIG DRAIN WIRE DRAIN WIRE DISPLAY SIG + DISPLAY RESET SIG ELECTRONIC BRAKE CONTROL MODULE (W/ NAVIGATION) (NEAR BRAKE MASTER CYLINDER) ENABLE SIG GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INFO DISPLAY MODULE (W/O NAVIGATION) (IF EQUIPPED) (BEHIND CENTER OF DASH) NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE USB CABLE 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 VIO WIRE W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Radio circuit, without amplifier (1 of 3) -> STACK DATA LOW

stack data low wiring diagram (8 of 8)

Chevrolet Cruze I facelift (2012-2015) stack data low wiring diagram (8 of 8)

BAT POS VOLT BLK WIRE BLK/GRY WIRE BRN/GRN WIRE CAMERA SIG 2 CELLULAR PHONE NAVIGATION, DIGITAL RADIO ANTENNA COAX DATA SHIELD DISPLAY RESET SIG DISPLAY SIG + DRAIN WIRE ELECTRONIC BRAKE CONTROL MODULE ENABLE SIG FUSE 5 GRN/BLU WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/GRN WIRE GRY/YEL WIRE HOT W/ BATTERY SAVER RELAY 1 ENERGIZED INFO DISPLAY MODULE INFO DISPLAY MODULE (W/ NAVIGATION) (BEHIND CENTER OF DASH) INSTRUMENT PANEL FUSE BLOCK LF SPD SENS SIG LO REF NAVIGATION ANTENNA SIGNAL SPLITTER NAVIGATION SYSTEM NCA WIRE NETWORK BUS 10 RADIO RADIO CONTROLS (W/O NAVIGATION) RED/GRN WIRE RESET SIG SENS SIG STACK DATA HIGH STACK DATA LOW STACK RESET SIG STACK SHIELD USB CABLE VIO WIRE VOICE AUDIO SIG W/ NAVIGATION W/O NAVIGATION WAKE UP SIG WHT/BLU WIRE YEL WIRE

Go to component -> Radio circuit, w/o amplifier (1 of 3) -> STACK DATA LOW
