Chevrolet Cruze I facelift (2012-2015) serial data comm enable Wiring diagrams

This page contains all the electrical diagrams for the component. serial data comm enable, in which he is found in the car Chevrolet Cruze I facelift (2012-2015). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram serial data comm enable (1 of 3)

Wiring diagram serial data comm enable for Chevrolet Cruze I facelift (2012-2015) (1 of 3)

Get access

ACCESSORY WAKEUP SER DATA ANTI-LOCK BRAKES SYSTEM ANTI-LOCK BRAKES SYSTEM POWER DISTRIBUTION SYSTEM ANTI-THEFT SYSTEM BACKUP LP CTRL BATT POSITIVE VOLT BATTERY BATTERY POSITIVE VOLTAGE BLK WIRE BLK/VIO WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BODY CONTROL MODULE (UNDER CENTER DASH) BRN WIRE BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE BRN/YEL WIRE CHILD SECURITY LOCK CTRL CLOSURE HANDLE SW OPEN SIG CLOSURE HANDLE SW OPEN SIG NETWORK BUS 1 COMPUTER DATA LINES SYSTEM CRUISE/ETC/TCC BRAKE SIG CURRENT SENS LW REF CURRENT SENS LW REF RR STOP LP SPLY VOLT CURRENT SENS SIG CURRENT SENS SPLY VOLT DK BLU WIRE DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM DOOR LOCKS SYSTEM POWER DISTRIBUTION SYSTEM DOOR LOCKS SYSTEM SHIFT INTERLOCK SYSTEM INTERIOR LIGHTS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DR LK ACTUATOR LK CTRL DR LK ACTUATOR UNLK CTRL DR LK CTRL ENABLE SIG ENABLE SIG PARK LK SOL CTRL TRUNK LP CTRL FOG LP RELAY CTRL FRT WINDSHIELD WIPER SW HI SIG FUSE 31 FUSE 32 FUSE 69 GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/VIO WIRE GRN/WHT WIRE GRN/YEL WIRE GROUND GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/GRN WIRE GRY/YEL WIRE HDLP HI BEAM RELAY CTRL HDLP HI BEAM RELAY CTRL HORN RELAY CTRL HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HEADLIGHTS SYSTEM HORNS SYSTEM HI SPEED GMLAN SER DATA (+) HI SPEED GMLAN SER DATA (-) HI SPEED GMLAN SER DATA (-) HOOD AJAR SWITCH SIGNAL HORN RELAY CTRL HORNS SYSTEM HOT AT ALL TIMES IGNITION 3 RELAY CONTROL IGNITION VOLTAGE INADVERTENT LOAD 1 SPLY VOLT INADVERTENT PWR CTRL INTERIOR LIGHTS SYSTEM INTERIOR LIGHTS SYSTEM EXTERIOR LIGHTS SYSTEM INTR LP CTR LED BACKLT DIMMING CTRL LEFT HDLP LO BEAM CTRL LEFT PARK LAMP CONTROL LF TURN SIG LP CTRL LIFT GATE AJAR SW SIG LIFT GLASS/TRUNK MTR REL CTRL LIFT GLASS/TRUNK MTR REL CTRL CRUISE/ETC/TCC BRAKE SIG FOG LP RELAY CTRL LO SPEED GMLAN SER DATA LOGISTICS RLY CTRL LR CHILD SECURTY LK MTR STATUS SIG LR STOP LP SPLY VOLT LR TURN SIG LP CTRL NETWORK BUS 1 NETWORK BUS 3 PARK BRAKE SW SIG 16 17 TECHNOLOGY IDENTIFICATION PARK LK SOL CTRL POWER DISTRIBUTION SYSTEM POWER DISTRIBUTION SYSTEM DOOR LOCKS SYSTEM REAR LICENSE LP CTRL RED WIRE RED/BRN WIRE RED/VIO WIRE RED/WHT WIRE RF TURN SIG LP CTRL RIGHT HDLP LO BEAM CTRL RIGHT PARK LAMP CONTROL RR CHILD SECURTY LK MTR STATUS SIG RR STOP LP SPLY VOLT RR TURN SIG LP CTRL SERIAL DATA COMM ENABLE SHIFT INTERLOCK SYSTEM INTERIOR LIGHTS SYSTEM STARTING/CHARGING SYSTEM STARTING/CHARGING SYSTEM EXTERIOR LIGHTS SYSTEM STOP LP RLY COIL CTRL TRUNK LP CTRL TRUNK, TAILGATE, FUEL DOORS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM COMPUTER DATA LINES SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM EXTERIOR LIGHTS SYSTEM HEADLIGHTS SYSTEM UNDERHOOD FUSE BLOCK UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER) VIO WIRE VIO/BLK WIRE VIO/GRY WIRE VIO/WHT WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE WHT/YEL WIRE WINDSHIELD WASHER RLY CTRL WIPER MTR PARK SW SIG WIPER MTR RLY COIL CTRL WIPER/WASHER SYSTEM WIPER/WASHER SYSTEM POWER DISTRIBUTION SYSTEM YEL WIRE YEL/BLU WIRE

Go to component -> Body control modules circuit (2 of 2) -> SERIAL DATA COMM ENABLE

Wiring diagram serial data comm enable (2 of 3)

Wiring diagram serial data comm enable for Chevrolet Cruze I facelift (2012-2015) (2 of 3)

Get access

2 7 LO SPD GMLAN SERIAL DATA LO SPD GMLAN SERIAL DATA 22 23 ACC WAKEUP SERIAL DATA SERIAL DATA COMM ENABLE 24 25 HI SPD GMLAN SERIAL DATA - HI SPD GMLAN SERIAL DATA + 4 3 INTERCONNECT BUS 9 LO SPD GMLAN SERIAL DATA ACC WAKEUP SERIAL DATA BLK WIRE BLU WIRE BLU/YEL WIRE BREAKOUT) BRN/WHT WIRE DATA LINK CONNECTOR DATA LINK CONNECTOR (LOWER LEFT SIDE OF DASH) DRIVER WINDOW MOTOR DRIVER WINDOW MOTOR (DRIVER'S DOOR) DRIVER WINDOW SWITCH DRIVER'S DOOR FUSE 14 GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GRN/YEL WIRE HI SPD GMLAN SERIAL DATA HOT AT ALL TIMES HVAC CONTROL MODULE (CENTER OF DASH) HVAC CONTROLS INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER CENTER CONSOLE) INSTRUMENT CLUSTER INSTRUMENT PANEL FUSE BLOCK INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH) INTERCONNECT BUS 1 INTERCONNECT BUS 3 INTERCONNECT BUS 4 INTERCONNECT BUS 9 KEYLESS ENTRY CONTROL MODULE KEYLESS ENTRY CONTROL MODULE (RIGHT KICK PANEL) LEFT REAR WINDOW SWITCH LEFT SIDE OBJECT SENSOR MODULE LO SPD GMLAN LO SPD GMLAN SERIAL DATA MULTI-AXIS ACCELERATION SENSOR MULTI-AXIS ACCELERATION SENSOR (UNDER CENTER CONSOLE) MULTIMEDIA PLAYER INTERFACE MODULE PASSENGER PRESENCE DETECTION MODULE PASSENGER PRESENCE DETECTION MODULE (UNDER FRONT OF PASSENGER'S SEAT) PASSENGER WINDOW SWITCH RADIO REAR PARKING ASSIST CONTROL MODULE REAR PARKING ASSIST CONTROL MODULE (LEFT SIDE OF LUGGAGE COMPT) RED/BLU WIRE RIGHT REAR WINDOW SWITCH RIGHT SIDE OBJECT SENSOR MODULE SEAT HEATING CONTROL MODULE SEAT HEATING CONTROL MODULE (UNDER FRONT OF DRIVER'S SEAT) SERIAL DATA SERIAL DATA COMM ENABLE STEERING ANGLE SENSOR (BASE OF STEERING COLUMN) STEERING COLUMN LOCK MODULE STEERING COLUMN LOCK MODULE (IF EQUIPPED) (UNDER LEFT SIDE OF DASH) SUNROOF CONTROL MODULE SUNROOF CONTROL MODULE (FRONT CENTER OF ROOF) VIO/YEL WIRE W/ AUDIO INTERFACE W/ EXPRESS UP/DOWN WINDOW WHT WIRE WHT/BLU WIRE

Go to component -> Computer data lines circuit (1 of 2) -> SERIAL DATA COMM ENABLE
