Chevrolet Cruze I facelift (2012-2015) reduced engine power ind Wiring diagram
This page shows the only wiring diagram for the component.reduced engine power ind, which is found in the car Chevrolet Cruze I facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram reduced engine power ind (1 of 1)
"CHECK ENGINE" IND CTRL
ABS IND.
AIR BAG IND
AMBIENT AIR TEMPERATURE SENSOR
AMBIENT AIR TEMPERATURE SENSOR (LEFT SIDE OF LEFT FOGLIGHT)
BATT POSITIVE VOLT
BATT POSITIVE VOLT IGN VOLT
BLK WIRE
BLK/BLU WIRE
BLK/BRN WIRE
BLU/GRY WIRE
BRAKE IND
BRN/WHT WIRE
CHARGING IND
CHECK ENGINE IND CTRL WAIT TO START IND CTRL
COMPUTER DATA LINES SYSTEM
CRUISE IND
DRIVER INFORMATION CENTER (DIC) DISPLAY
DRIVER INFORMATION CENTER SELECT MENU SW SIG
DRIVER INFORMATION CENTER SW SIG
DRL IND
ENGINE CONTROLS SYSTEM
ENGINE COOLANT TEMPERATURE GAUGE
ESC OFF IND
FOG LAMPS IND
FUEL GAUGE
FUSE 21 FUSE 23
FUSE 23
FUSE 52
GRN WIRE
GRN/WHT WIRE
GRY/BLU WIRE
HIGH BEAM IND
HOT AT ALL TIMES
HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK FUSE 21 (BEHIND LEFT END OF DASH)
HOT W/ IGNITION MAIN RELAY ENERGIZED
IGN VOLT
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
LEFT TURN IND
LIGHTS ON IND
LO REF
LO SPD GMLAN SERIAL DATA
LOGIC
LOW FUEL WARNING LAMP IND
LOW TIRE PRESSURE IND
MALFUNCTION IND
MASTER LIGHTING SW IND
MENU
OUTSIDE AMBIENT AIR TEMP SENSOR SIGNAL
OUTSIDE AMBIENT TEMP SENS LO REF
PARK LAMPS IND
PARKING ASSIST IND
POWER STEERING WARNING LIGHT IND
RED/GRY WIRE
RED/WHT WIRE
REDUCED ENGINE POWER IND
RIGHT TURN IND
SEAT BELT IND
SECURITY IND
SET-
SPEEDOMETER
STRUT TOWER)
TACHOMETER
TCS OFF IND
TCS/ESC IND
TURN SIGNAL/ MULTI-FUNCTION SWITCH
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT
VIO/WHT WIRE
WAIT TO START IND CTRL
Go to component -> Instrument cluster circuit (1 of 2) -> REDUCED ENGINE POWER IND
