Chevrolet Cruze I facelift (2012-2015) rear defogger switch logic Wiring diagram
This page shows the only wiring diagram for the component.rear defogger switch logic, which is found in the car Chevrolet Cruze I facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear defogger switch logic (1 of 1)
BATTERY FUSE BLOCK
BATTERY FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
BLK WIRE
BRN/VIO WIRE
BRN/YEL WIRE
DEF RLY CTRL
DRIVER OUTSIDE REARVIEW MIRROR
FUSE 28
FUSE 5
FUSE 60
GRN/YEL WIRE
HOT AT ALL TIMES
HVAC CONTROL MODULE
HVAC CONTROL MODULE (CENTER OF DASH)
HVAC CONTROLS
LOGIC
NETWORK BUS 9
PASSENGER DRIVER OUTSIDE OUTSIDE REARVIEW REARVIEW MIRROR MIRROR
PASSENGER OUTSIDE REARVIEW MIRROR
REAR DEFOGGER GRID
REAR DEFOGGER IND
REAR DEFOGGER RELAY
REAR DEFOGGER SWITCH
REAR DEFOGGER SWITCH LOGIC
RED/WHT WIRE
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
W/ MANIFOLD OUTSIDE MIRROR
