Chevrolet Cruze I facelift (2012-2015) low ref rf end sensor sig lh middle impact sensing mod low ref Wiring diagram
This page shows the only wiring diagram for the component.low ref rf end sensor sig lh middle impact sensing mod low ref, which is found in the car Chevrolet Cruze I facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram low ref rf end sensor sig lh middle impact sensing mod low ref (1 of 1)
1 1 RH ROOF RAIL MOD HIGH CTRL RH ROOF RAIL MOD LOW CTRL
13-14, 15-16, 17-18, 37-38, 39-40, 53-54)
BAR
BLK WIRE
BLK/BLU WIRE
BLK/ORG WIRE
BLU/BRN WIRE
BRN/ORG WIRE
DRIVER SEAT AIR BAG
DRIVER SEAT BELT ANCHOR PRE- TENSIONER
DRIVER SEAT BELT BUCKLE
DRIVER SEAT BELT RETRACTOR PRETENSIONER
DRIVER SEAT BELT SWITCH
DRIVER SEAT BELT SWITCH DRIVER SEAT BELT BUCKLE
DRV ST BELT ANCHOR PRETR
GRN/ORG WIRE
GRN/WHT WIRE
GRY/ORG WIRE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE
INFLATABLE RESTRAINT SENSING, DIAGNOSTIC MODULE (UNDER CENTER CONSOLE)
LEFT FRONT SIDE IMPACT SENSOR
LEFT REAR SEAT AIR BAG
LEFT REAR SIDE IMPACT SENSOR
LEFT REAR SIDE IMPACT SENSOR (BASE OF LEFT "C" PILLAR)
LEFT ROOF RAIL AIR BAG
LEFT ROOF RAIL MOD HIGH
LEFT ROOF RAIL MOD LOW
LF END SENSOR SIG
LF SIDE IMPACT MOD HIGH
LF SIDE IMPACT MOD LOW
LF SIDE IMPACT SENSING MOD
LH PRETENSIONER HIGH
LH PRETENSIONER LOW
LH SEAT BELT SW
LH SEAT BELT SW LOW REF
LH SEAT BELT SW LOW REF RH SEAT BELT SW LOW REF RH SEAT BELT SW SIG
LOW REF
LOW REF RF END SENSOR SIG LH MIDDLE IMPACT SENSING MOD LOW REF
LOW REF RH MIDDLE IMPACT SENSING MOD
LR SIDE IMPACT SIR INF CTRL
LR SIDE IMPACT SIR INF SPLY
LT GRN WIRE
NCA WIRE
ORG/ WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/DK BLU WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/RED WIRE
ORG/VIO WIRE
ORG/YEL WIRE
PASS ST BELT ANCHOR PRETR
PASSENGER SEAT AIR BAG
PASSENGER SEAT BELT ANCHOR PRE- TENSIONER
PASSENGER SEAT BELT BUCKLE
PASSENGER SEAT BELT RETRACTOR PRETENSIONER
PASSENGER SEAT BELT SWITCH
PASSENGER SEAT BELT SWITCH PASSENGER SEAT BELT BUCKLE
RED WIRE
RF SIDE IMPACT MOD HIGH
RF SIDE IMPACT MOD LOW
RF SIDE IMPACT SENSING MOD
RH PRETENSIONER HIGH
RH PRETENSIONER LOW
RH ROOF RAIL MOD HIGH CTRL
RH ROOF RAIL MOD LOW CTRL
RH SEAT BELT SW LOW REF
RH SEAT BELT SW SIG
RIGHT FRONT IMPACT SENSOR
RIGHT FRONT IMPACT SENSOR (RIGHT SIDE OF RADIATOR SUPPORT)
RIGHT FRONT SIDE IMPACT SENSOR
RIGHT REAR SEAT AIR BAG
RIGHT REAR SIDE IMPACT SENSOR
RIGHT REAR SIDE IMPACT SENSOR (BASE OF RIGHT "C" PILLAR)
RIGHT ROOF RAIL AIR BAG
RR SIDE IMPACT SIR INF CTRL
RR SIDE IMPACT SIR INF SPLY
SEAT BELT REMINDER SIG
SENSING MOD
SENSING MOD LOW REF LOW REF RH MIDDLE IMPACT
SHORTING
SHORTING BAR
VIO/ORG WIRE
WHT WIRE
WHT/BLK WIRE
WHT/ORG WIRE
YEL/ORG WIRE
Go to component -> Supplemental restraints circuit (1 of 2) -> LOW REF RF END SENSOR SIG LH MIDDLE IMPACT SENSING MOD LOW REF
