Chevrolet Cruze I facelift (2012-2015) lo ref lo ref Wiring diagram
This page shows the only wiring diagram for the component.lo ref lo ref, which is found in the car Chevrolet Cruze I facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lo ref lo ref (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 DRV ELEMENT RTN PASS ELEMENT RTN
BLK WIRE
BLU WIRE
COMPUTER DATA LINES SYSTEM
DRIVER BACK HEATED SEAT ELEMENT
DRIVER BACK HEATED SEAT ELEMENT (UNDER UPHOLSTERY OF DRIVER'S SEAT BACK)
DRIVER CUSHION HEATED SEAT ELEMENT
DRIVER CUSHION HEATED SEAT ELEMENT (UNDER UPHOLSTERY OF DRIVER'S SEAT BOTTOM)
DRIVER HEATED SEAT SWITCH
DRV ELEMENT RTN
DRV HTD VOLT
DRV NTC SIG
DRV NTC SIG PASS NTC SIG
FUSE
FUSE 33
GMLAN SERIAL DATA
GND B+
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HVAC CONTROLS
LO REF
LO REF LO REF
LOGIC
NCA WIRE
NETWORK BUS 9
PASS ELEMENT RTN DRV HTD VOLT
PASS HTD VOLT
PASS NTC SIG
PASSENGER BACK HEATED SEAT ELEMENT
PASSENGER BACK HEATED SEAT ELEMENT (UNDER UPHOLSTERY OF PASSENGER'S SEAT BACK)
PASSENGER CUSHION HEATED SEAT ELEMENT
PASSENGER HEATED SEAT SWITCH
RED WIRE
RED/WHT WIRE
SEAT HEATING CONTROL MODULE
SEAT HEATING CONTROL MODULE (UNDER FRONT OF DRIVER'S SEAT)
UNDERHOOD FUSE BLOCK
UNDERHOOD FUSE BLOCK (ENGINE COMPT, NEXT TO LEFT STRUT TOWER)
YEL WIRE
Go to component -> Heated seats circuit -> LO REF LO REF
