Chevrolet Cruze I facelift (2012-2015) driver traction door lock switch control switch Wiring diagram
This page shows the only wiring diagram for the component.driver traction door lock switch control switch, which is found in the car Chevrolet Cruze I facelift (2012-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver traction door lock switch control switch (1 of 1)
6 SPEED A/T
BLK WIRE
BODY CONTROL MODULE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DRIVER DOOR LOCK SWITCH
DRIVER LOGIC WINDOW SWITCH
DRIVER TRACTION DOOR LOCK SWITCH CONTROL SWITCH
DRIVER WINDOW SWITCH
ENGINE START)
FUSE 23
GRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
HDLP SW PRK LP SIG
HEAD
HEADLAMP SWITCH
HOT AT ALL TIMES
IGNATION MODE SWITCH (W/ KEYLESS
IGNITION MODE SWITCH
ILLUMINATION
INSTRUMENT CLUSTER
INSTRUMENT PANEL FUSE BLOCK
INSTRUMENT PANEL FUSE BLOCK (BEHIND LEFT END OF DASH)
LED BACKLIGHT DIMMING CTRL
LEFT REAR LOGIC WINDOW SWITCH
LEFT REAR WINDOW SWITCH
LEFT STEERING WHEEL CONTROL SWITCH
LIGHTING CTRL SW REF
LIGHTING CTRL SW SIG
LOGIC
LOW SPD GMLAN SERIAL DATA
NETWORK 3
OFF AUTO
OFF AUTO PARK HEAD
OUTSIDE REARVIEW MIRROR SWITCH
PARK
PASSENGER LOGIC WINDOW SWITCH
PASSENGER WINDOW SWITCH
RED/GRY WIRE
RIGHT REAR WINDOW SWITCH
RIGHT REAR WINDOW SWITCH LOGIC
RIGHT STEERING WHEEL CONTROL SWITCH
STEERING WHEEL AIR BAG COIL
SUNROOF SWITCH
SUNROOF TILT SWITCH
TRACTION CONTROL SWITCH
TRANSMISSION SHIFT LEVER POSITION INDICATOR
W/ CRUISE CONTROL
W/ KEYLESS ENGINE START
WHT/BRN WIRE
WHT/RED WIRE
YEL WIRE
Go to component -> Instrument illumination circuit -> DRIVER TRACTION DOOR LOCK SWITCH CONTROL SWITCH
