Chevrolet Cruze I facelift (2012-2015) 13 18 fog lp relay ctrl hi beam relay ctrl Wiring diagram

1 2 RH LOW BEAM CTRL LH LOW BEAM CTRL 13 18 FOG LP RELAY CTRL HI BEAM RELAY CTRL 23 24 10 3 2 HS GMLAN - HS GMLAN + AMBIENT LT SENS SIG B+ 4 11 17 LIGHT CTRL SW REF DIM SW HI BEAM SIG FLASH TO PASS SIG AMBIENT LIGHT/ SUNLOAD SENSOR AMBIENT LIGHT/ SUNLOAD SENSOR (FRONT CENTER OF DASH) AMBIENT LT SENS SIG AUTO BATTERY FUSE BLOCK BATTERY FUSE BLOCK (ENGINE COMPT, BLK WIRE BLU WIRE BLU/VIO WIRE BODY CONTROL MODULE (BCM) (UNDER CENTER DASH) BRN/GRN WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/WHT WIRE CENTER SPEAKER COMPUTER DATA LINES SYSTEM CRUISE CONTROL SYSTEM DIM SW HI BEAM SIG DRL IND FLASH TO PASS SIG FOG LP RELAY CTRL FRONT FOG LAMP IND FRONT FOG LAMP RELAY FRONT FOG LAMP SWITCH FUSE FUSE 24 FUSE 3 FUSE 37 FUSE 38 FUSE 48 FUSE 5 FUSE 52 FUSE 8 FUSE 9 FUSE FUSE GMLAN GRN WIRE GRN/BRN WIRE GRN/GRY WIRE GROUND HDLP OFF SIG CTRL HDLP SW ON SIG HDLP SW PRK LP SIG HEAD HEADLAMP HIGH BEAM RELAY HEADLAMP SWITCH HI BEAM RELAY CTRL HIGH BEAM IND HIGH BEAM IND DRL IND HIGH BEAM SW HOT AT ALL TIMES HOT AT ALL TIMES INSTRUMENT PANEL FUSE BLOCK FUSE FUSE (BEHIND LEFT END OF DASH) HOT W/ IGNITION MAIN RELAY ENERGIZED HS GMLAN - IGN INSTRUMENT PANEL FUSE BLOCK LEFT FRONT FOG LAMP LEFT HEADLAMP LH LOW BEAM CTRL LIGHT CTRL SW REF LIGHT CTRL SW SIG LO SPD LO SPD GMLAN LOGIC INSTRUMENT CLUSTER NEXT TO LEFT STRUT TOWER) OFF PARK PARK BRAKE SWITCH PARK BRAKE SWITCH (CENTER CONSOLE, ATTACHED TO PARKING BRAKE) PARK BRK SW SIG RED/BLU WIRE RED/BRN WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RH LOW BEAM CTRL RIGHT FRONT FOG LAMP RIGHT HEADLAMP SER DATA TURN SIGNAL/ MULTI-FUNCTION SWITCH UNDER- HOOD FUSE BLOCK UNDERHOOD FUSE BLOCK VIO/BRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/VIO WIRE YEL WIRE YEL/BRN WIRE
