Chevrolet Corvette C8 (2020-2024) w/ audio file speaker system Wiring diagram
This page shows the only wiring diagram for the component.w/ audio file speaker system, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/ audio file speaker system (1 of 1)
AUDIO AMPLIFIER
AUXILIARY COOLING FAN MOTOR 1
AUXILIARY COOLING FAN MOTOR 2
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
CAN BUS (+) 5 SER DATA
ETHERNET BUS 15 (-)
ETHERNET BUS 2 (-)
ETHERNET BUS 4 (-)
ETHERNET BUS 6 (-)
FRONT HEATER, AIR CONDITIONING USER INTERFACE CONTROL
GRN/BLK WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GRY WIRE
GRY/WHT WIRE
HEAD-UP DISPLAY
LEFT FRONT HEADLAMP
LIN BUS 1
LOGIC
RADIO
RIGHT FRONT HEADLAMP
SER DATA CAN BUS (-) 5
STEERING WHEEL AIR BAG COIL
STEERING WHEEL RADIO CONTROL SWITCH
TELEMATIC CONTROL MODULE
VEHICLE PERFORMANCE DATA RECORDER
W/ AUDIO FILE SPEAKER SYSTEM
W/ GROUND CLEARANCE BODY HEIGHT
W/ VEHICLE COMMUNICATION SYSTEM
W/ VEHICLE PERFORMANCE RECORDER
W/O AUDIO FILE SPEAKER SYSTEM
W/O INDUCTIVE PORTABLE WIRELESS DEVICE CHARGER
W/O VEHICLE COMMUNICATION SYSTEM
W/O VEHICLE PERFORMANCE RECORDER
WHT WIRE
WIRELESS ACCESSORY CHARGING MODULE
Go to component -> Computer data lines circuit (5 of 6) -> W/ AUDIO FILE SPEAKER SYSTEM
