Chevrolet Corvette C8 (2020-2024) transmission output speed sensor control Wiring diagram
This page shows the only wiring diagram for the component.transmission output speed sensor control, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram transmission output speed sensor control (1 of 1)
ACCELERATOR PEDAL POSITION SENSOR (TOP OF ACCELERATOR PEDAL ASSEMBLY)
AUTOMATIC TRANSMISSION ASSEMBLY
AUTOSAR CAN BUS (+) 2 SERIAL DATA
BLK/BLU WIRE
BLK/BRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BLU WIRE
BLU/YEL WIRE
BRAKE PEDAL POSITION SENSOR
BRN/RED WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROLS SYSTEM
EVEN GEARS AUTOMATIC TRANSMISSION INPUT SPEED SENSOR
EVEN GEARS SENSOR ASSEMBLY
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
NCA WIRE
ORG/ WIRE
OUTPUT SPEED SIGNAL
RED WIRE
TRANSMISSION CONTROL MODULE (FORWARD OF RIGHT WHEEL LINER)
TRANSMISSION INPUT SPEED SENSOR GROUND
TRANSMISSION INPUT SPEED SENSOR SIGNAL
TRANSMISSION OUTPUT SHAFT SPEED SENSOR
TRANSMISSION OUTPUT SPEED SENSOR CONTROL
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL/BRN WIRE
YEL/WHT WIRE
Go to component -> Cruise control circuit (2 of 2) -> TRANSMISSION OUTPUT SPEED SENSOR CONTROL
