Chevrolet Corvette C8 (2020-2024) trans tap up sw sig Wiring diagram
This page shows the only wiring diagram for the component.trans tap up sw sig, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram trans tap up sw sig (1 of 1)
5.5L
6.2L
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/GRY WIRE
BLU/YEL WIRE
BUS (+2) SER DATA
BUS (-) SER DATA
CAMSHAFT W 2 LOW REF
COMPUTER DATA LINES SYSTEM
CRANKSHAFT POS SENS REPLICATED SIG
ENGINE CONTROL MODULE
ENGINE CONTROLS SYSTEM
GRN/VIO WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LEFT AUTOMATIC TRANSMISSION MANUAL SHIFT AUXILIARY POSITION SWITCH
LIN BUS 1
POS SENS SIG
PWR MODULE WAKEUP SIG
REAR BODY WIRING HARNESS JUNCTION BLOCK
RED/GRY WIRE
RIGHT AUTOMATIC TRANSMISSION MANUAL SHIFT AUXILIARY POSITION SWITCH
RUN/CRANK IGN 1 VOLT 2
SIG GROUND
STEERING WHEEL AIR BAG COIL
TRANS TAP DOWN SW SIG
TRANS TAP UP SW LOW REF
TRANS TAP UP SW SIG
TRANSMISSION CONTROL MODULE (FORWARD OF RIGHT WHEEL LINER)
VIO/BLU WIRE
VIO/GRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT WIRE
YEL/BLU WIRE
Go to component -> Transmission circuit (5 of 5) -> TRANS TAP UP SW SIG
