Chevrolet Corvette C8 (2020-2024) right folding top stowage compartment lid motor Wiring diagram
This page shows the only wiring diagram for the component.right folding top stowage compartment lid motor, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right folding top stowage compartment lid motor (1 of 1)
BATT POS VOLT
BLK WIRE
BLU/GRN WIRE
BLU/VIO WIRE
CAN SERIAL DATA (-) 4
CLOSED SENSOR FOLDING TOP FRONT LATCH ACTUATOR
CLOSED SIG
COMPUTER DATA LINES SYSTEM
DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH
FOLDING TOP FRONT LATCH ACTUATOR MOTOR
GRN WIRE
GRN/GRY WIRE
GRN/YEL WIRE
LATCH CLOSED SIG
LATCH CTRL
LATCH OPEN SIG
LOGIC
NCA WIRE
OPENED SENSOR FOLDING TOP FRONT LATCH ACTUATOR
RED WIRE
RIGHT FOLDING TOP CONTROL MODULE (PART OF FOLDING TOP ASSEMBLY)
RIGHT FOLDING TOP MOTOR
RIGHT FOLDING TOP STOWAGE COMPARTMENT CONTROL MODULE
RIGHT FOLDING TOP STOWAGE COMPARTMENT LID MOTOR
RIGHT FOLDING TOP STOWAGE COMPARTMENT LOCKED SENSOR
ROOF CLOSED LOCKED SENSOR FOLDING TOP FRONT LATCH STRIKER
ROOF PANELS STOWED SENSOR FOLDING TOP SIDE RAIL
RR TONNEAU LOCKED SIG
SENS SPLY VOLT (2)
STOWED SIG
TONNEAU SENS SPLY VOLT 2
UNLATCH CTRL
VIO WIRE
WHT WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Power top/sunroof circuit (2 of 2) -> RIGHT FOLDING TOP STOWAGE COMPARTMENT LID MOTOR
