Chevrolet Corvette C8 (2020-2024) rh frt mirr mtr fold out ctrl Wiring diagram
This page shows the only wiring diagram for the component.rh frt mirr mtr fold out ctrl, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rh frt mirr mtr fold out ctrl (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BODY CTRL MOD LIN BUS 3
BRN/VIO WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
GRN WIRE
GRN/BLK WIRE
GRN/GRY WIRE
GRN/YEL WIRE
GROUND 19
GRY WIRE
LF MIRR MTR RH (+) LH (-) CTRL
NAVIGATION SYSTEM
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
PASSENGER OUTSIDE REAR VIEW MIRROR
PASSENGER OUTSIDE REAR VIEW MIRROR FOLDING MOTOR
PASSENGER OUTSIDE REAR VIEW MIRROR GLASS
PASSENGER OUTSIDE REAR VIEW MIRROR MOTOR
PASSENGER SIDE OBJECT DETECTION INDICATOR
PNK/BLK WIRE
RED WIRE
RED/WHT WIRE
RF MIRR MTR UP (+) DOWN (-) CTRL
RH FRT MIRR MTR COM CTRL
RH FRT MIRR MTR FOLD IN CTRL
RH FRT MIRR MTR FOLD OUT CTRL
RIGHT OUTSIDE REAR VIEW MIRROR TURN SIGNAL LAMP
SECONDARY FUSED BATT POS VOLT 80
VIO WIRE
WHT WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Power mirrors circuit (2 of 2) -> RH FRT MIRR MTR FOLD OUT CTRL
