Chevrolet Corvette C8 (2020-2024) pass seat belt sens sig Wiring diagram
This page shows the only wiring diagram for the component.pass seat belt sens sig, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pass seat belt sens sig (1 of 1)
BLK/ORG WIRE
BLU/ORG WIRE
BRN/ORG WIRE
DRIVER FRONT SEAT BELT ANCHOR PLATE TENSIONER
DRIVER FRONT SEAT BELT RETRACTOR
DRIVER SEAT BELT SWITCH DRIVER FRONT SEAT BELT BUCKLE
DRV SEAT BACK AIR BAG HI CTRL
DRV SEAT BACK AIR BAG LO CTRL
DRV SEAT BELT HI CTRL
DRV SEAT BELT LO CTRL
DRV SEAT BELT SENS SIG
DRV SEAT BELT SW LO REF
GRY/ORG WIRE
LEFT AIR BAG FRONT END DISCRIMINATING SENSOR
LF SENS LO REF LF DISCRIMINATING SENS SIG
LF SIDE IMPACT SENS SIG
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
ORG/WHT WIRE
ORG/YEL WIRE
PASS SEAT BACK AIR BAG HI CTRL
PASS SEAT BACK AIR BAG LO CTRL
PASS SEAT BELT HI CTRL
PASS SEAT BELT LO CTRL
PASS SEAT BELT SENS SIG
PASSENGER FRONT SEAT BELT ANCHOR PLATE TENSIONER
PASSENGER FRONT SEAT BELT RETRACTOR
PASSENGER SEAT BELT SWITCH PASSENGER FRONT SEAT BELT BUCKLE
RESTRAINTS CONTROL MODULE (UNDER CENTER CONSOLE)
RF SIDE IMPACT SENS LO REF
RF SIDE IMPACT SENS SIG
RIGHT AIR BAG FRONT END DISCRIMINATING SENSOR
RIGHT DOOR AIR BAG SIDE IMPACT SENSOR
VIO/ORG WIRE
WHT/ORG WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> PASS SEAT BELT SENS SIG
