Chevrolet Corvette C8 (2020-2024) on/off ind Wiring diagram
This page shows the only wiring diagram for the component.on/off ind, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram on/off ind (1 of 1)
A/C IND
A/C SWITCH
AIR INLET VALVE ACTUATOR
AUTO IND
AUTO SWITCH
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BLU/YEL WIRE
COMPUTER DATA LINES SYSTEM
DEFROST SWITCH
DEFROST, LOWER AIR OUTLET IND
DEFROST, LOWER AIR OUTLET SWITCH
FAN DOWN SWITCH
FAN UP SWITCH
FRONT HEATER, AIR CONDITIONING USER INTERFACE CONTROL
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/GRN WIRE
HEADLIGHTS SYSTEM
LEFT TEMPERATURE DOOR ACTUATOR
LEFT TEMPERATURE DOWN SWITCH
LEFT TEMPERATURE UP SWITCH
LOGIC
LOWER AIR OUTLET IND
LOWER AIR OUTLET SWITCH
MODE VALVE ACTUATOR
ON/OFF IND
ON/OFF SWITCH
RECIRCULATION IND
RECIRCULATION SWITCH
RED/BRN WIRE
RED/WHT WIRE
RIGHT TEMPERATURE DOOR ACTUATOR
RIGHT TEMPERATURE DOWN SWITCH
RIGHT TEMPERATURE UP SWITCH
SUNLOAD, AMBIENT LIGHT, SECURITY INDICATOR SENSOR
SYNC IND
SYNC SWITCH
UPPER AIR OUTLET IND
UPPER AIR OUTLET SWITCH
UPPER, LOWER AIR OUTLET IND
UPPER, LOWER AIR OUTLET SWITCH
WHT/BLU WIRE
WHT/YEL WIRE
Go to component -> Automatic a/c circuit (2 of 5) -> ON/OFF IND
