Chevrolet Corvette C8 (2020-2024) object sens supply volt Wiring diagram
This page shows the only wiring diagram for the component.object sens supply volt, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram object sens supply volt (1 of 1)
BATT POSITIVE VOLT
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BRN/WHT WIRE
CAN BUS (-) 1 SERIAL DATA
COMPUTER DATA LINES SYSTEM
DRIVER INFORMATION CENTER DISPLAY
GRN/BLK WIRE
GROUND
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER CONTROL MODULE
LEFT REAR MIDDLE PARKING ASSIST SENSOR ALARM SENSOR
LEFT REAR OUTER PARKING ASSIST SENSOR ALARM SENSOR
LIN BUS 1
LOGIC
LR MIDDLE PARKING ASSIST SENS SIG
LR OUTER PARKING ASSIST SENS SIG
OBJECT SENS LOW REF
OBJECT SENS SUPPLY VOLT
PARKING ASSIST CONTROL MODULE
REAR BODY WIRING HARNESS JUNCTION BLOCK
RED/GRY WIRE
RIGHT REAR MIDDLE PARKING ASSIST SENSOR ALARM SENSOR
RIGHT REAR OUTER PARKING ASSIST SENSOR ALARM SENSOR
RR MIDDLE PARKING ASSIST SENS SIG
RR OUTER PARKING ASSIST SENS SIG
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/VIO WIRE
YEL/WHT WIRE
Go to component -> Parking assistant circuit -> OBJECT SENS SUPPLY VOLT
