Chevrolet Corvette C8 (2020-2024) lf mirr mtr com ctrl Wiring diagram
This page shows the only wiring diagram for the component.lf mirr mtr com ctrl, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lf mirr mtr com ctrl (1 of 1)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BODY CTRL MOD LIN BUS 3
BRN/BLK WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DOWN
DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH
DRIVER OUTSIDE REAR VIEW MIRROR FOLDING MOTOR
DRIVER OUTSIDE REAR VIEW MIRROR GLASS
DRIVER OUTSIDE REAR VIEW MIRROR MOTOR
DRIVER OUTSIDE REAR- VIEW MIRROR
DRIVER SIDE OBJECT DETECTION INDICATOR
FOLDING
GRN WIRE
GRN/YEL WIRE
GROUND 11
GRY WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
LEFT
LEFT OUTSIDE REAR VIEW MIRROR TURN SIGNAL LAMP
LF MIRR MTR COM CTRL
LF MIRR MTR FOLD IN CTRL
LF MIRR MTR FOLD OUT CTRL
LF MIRR MTR RH (+) LH (-) CTRL
LF MIRR MTR UP (+) DOWN (-) CTRL
LOGIC
NAVIGATION SYSTEM
PNK/BLK WIRE
REAR BODY FUSE BLOCK
RED WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT
SECONDARY FUSED BATT POS VOLT 79
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/GRN WIRE
WHT/GRY WIRE
YEL/BRN WIRE
Go to component -> Power mirrors circuit (1 of 2) -> LF MIRR MTR COM CTRL
