Chevrolet Corvette C8 (2020-2024) htd steering wheel low ctrl Wiring diagram
This page shows the only wiring diagram for the component.htd steering wheel low ctrl, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram htd steering wheel low ctrl (1 of 1)
BLK WIRE
BLK/WHT WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SWITCH
GRN/BLK WIRE
GRY/YEL WIRE
HEATED STEERING WHEEL MODULE
HOT AT ALL TIMES
HTD STEERING WHEEL HIGH CTRL
HTD STEERING WHEEL LOW CTRL
HTD STEERING WHEEL SW LED CTRL
HTD STEERING WHEEL SW SIG
HTD STEERING WHEEL TEMP SENS SIG
HTD STEERING WHEEL VOLT REF
INDICATOR DIMMING CONTROL
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LOCAL INTERCONNECT NETWORK 12
LOGIC
RED WIRE
RED/BRN WIRE
STEERING WHEEL AIR BAG COIL
STEERING WHEEL HEATER
STEERING WHEEL HEATING IND
STEERING WHEEL HEATING SWITCH
STEERING WHEEL RADIO CONTROL SWITCH
VIO WIRE
VIO/BLU WIRE
WHT WIRE
WHT/YEL WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Heated steering wheel circuit -> HTD STEERING WHEEL LOW CTRL
