Chevrolet Corvette C8 (2020-2024) exh flow vlv ctrl 1 wiring diagram
This page shows the only wiring diagram for the component.exh flow vlv ctrl 1, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
exh flow vlv ctrl 1 wiring diagram (1 of 1)
BATT POS VOLT
BLK WIRE
BLU/WHT WIRE
BRN/GRN WIRE
CYLINDER DEACTIVATION EXHAUST CONTROL VALVE 2 ACTUATOR
CYLINDER DEACTIVATION EXHAUST CONTROL VALVE ACTUATOR
DEFOG GROUND
EXH FLAPPER VLV 3 FEEDBACK SIG
EXH FLAPPER VLV 4 FEEDBACK SIG
EXH FLOW VLV 1 FEEDBACK SIG
EXH FLOW VLV 2 FEEDBACK SIG
EXH FLOW VLV CTRL 1
EXH FLOW VLV CTRL 2
FUEL PUMP POWER CONTROL MODULE
GRN/VIO WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ IGNITION MAIN RELAY ENERGIZED
LOWER RIGHT FRONT OF ENGINE)
REAR BODY WIRING HARNESS JUNCTION BLOCK
RED/VIO WIRE
SOUND QUALITY EXHAUST CONTROL VALVE 2 ACTUATOR
SOUND QUALITY EXHAUST CONTROL VALVE ACTUATOR
VIO/GRN WIRE
VIO/WHT WIRE
VIO/YEL WIRE
YEL WIRE
Go to component -> 6.2l vin 4, electronic muffler circuit -> EXH FLOW VLV CTRL 1
