Chevrolet Corvette C8 (2020-2024) batt volt 80 Wiring diagram
This page shows the only wiring diagram for the component.batt volt 80, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram batt volt 80 (1 of 1)
BATT VOLT 79
BATT VOLT 80
BLK WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DOOR LOCKS SYSTEM
DOWN
DRIVER FRONT SIDE DOOR WINDOW CONTROL SWITCH
DRIVER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
EXPRESS
GND 11
GND 19
GRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
ILL
LIN BUS 3
LOGIC
PASSENGER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
PASSENGER FRONT SIDE DOOR WINDOW SWITCH
REAR BODY WIRING HARNESS JUNCTION BLOCK
RED/GRY WIRE
RED/VIO WIRE
RED/WHT WIRE
VIO/GRY WIRE
WHT/BRN WIRE
Go to component -> Power windows circuit -> BATT VOLT 80
