Chevrolet Corvette C8 (2020-2024) automatic transmission control indicator Wiring diagrams
This page contains all the electrical diagrams for the component. automatic transmission control indicator, in which he is found in the car Chevrolet Corvette C8 (2020-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
automatic transmission control indicator wiring diagram (1 of 2)
5.5L
6.2L
AMBIENT AIR TEMP SENS SIG
AMBIENT AIR TEMPERATURE SENSOR
AUTOMATIC TRANSMISSION CONTROL INDICATOR
AUTOSAR CAN BUS (+) 2 SERIAL DATA AUTOSAR CAN BUS (-) 2 SER DATA
AUTOSAR CAN BUS SERIAL DATA
BATT POSITIVE VOLT
BATTERY POSITIVE VOLTAGE
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/YEL WIRE
BODY CONTROL MODULE (BEHIND CENTER OF DASH)
BRN/BLU WIRE
CAN BUS (-) 2 SER DATA
COMPUTER DATA LINES SYSTEM
CTRL MOD LIN BUS 1
DRIVER FRONT SIDE DOOR LATCH
DRIVER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
ENGINE CONTROL MODULE
ENGINE CONTROLS SYSTEM
ENGINE OIL PRESSURE SENSOR
ENGINE OIL TEMPERATURE SENSOR
FUEL LEVEL SENSOR
FUEL PUMP POWER CONTROL MODULE
GEAR SHIFT CONTROL MODULE (ON CENTER CONSOLE)
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
ILL
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
LOGIC
OIL PRESS SENS SIG
OIL TEMP SENS SIG
PARKING BRAKE CONTROL SWITCH
PASSENGER FRONT SIDE DOOR LATCH
PASSENGER FRONT SIDE DOOR WINDOW REGULATOR MOTOR
RED/BLU WIRE
RED/GRY WIRE
SENS LOW REF
SENS LOW REF 1
SERIAL DATA CAN BUS (-)
TEMP SENS SIG
VIO WIRE
WHT WIRE
WHT/RED WIRE
YEL/BRN WIRE
Go to component -> Instrument cluster circuit (2 of 2) -> AUTOMATIC TRANSMISSION CONTROL INDICATOR
automatic transmission control indicator wiring diagram (2 of 2)
AUTOMATIC TRANSMISSION
AUTOMATIC TRANSMISSION CONTROL INDICATOR
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
ELECTRONIC
GEAR SHIFT CONTROL MODULE
GRN WIRE
GRY WIRE
GRY/RED WIRE
GRY/VIO WIRE
ILL
LOGIC
NCA WIRE
ORG/ WIRE
RED WIRE
RED/GRY WIRE
TRANSMISSION CONTROL SOLENOID VALVE 1
TRANSMISSION CONTROL SOLENOID VALVE 2
TRANSMISSION CONTROL SOLENOID VALVE 3
TRANSMISSION CONTROL SOLENOID VALVE 4
TRANSMISSION CONTROL SOLENOID VALVE 5
TRANSMISSION CONTROL SOLENOID VALVE 6
TRANSMISSION CONTROL SOLENOID VALVE 7
TRANSMISSION CONTROL SOLENOID VALVE 8
TRANSMISSION CONTROL SOLENOID VALVE 9
TRANSMISSION PARK LOCK STEPPER MOTOR
TRANSMISSION PARK VALVE LOCK SOLENOID ACTUATOR
VIO WIRE
VIO/BLU WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/GRN WIRE
WHT/RED WIRE
YEL WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component -> Transmission circuit (4 of 5) -> AUTOMATIC TRANSMISSION CONTROL INDICATOR
