Chevrolet Corvette C8 (2020-2024) accent lighting ctrl Wiring diagram
This page shows the only wiring diagram for the component.accent lighting ctrl, which is found in the car Chevrolet Corvette C8 (2020-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram accent lighting ctrl (1 of 1)
ACCENT LIGHTING CTRL
BATT POS VOLT
BLK WIRE
BODY CONTROL MODULE (BEHIND CENTER OF DASH)
BRN/VIO WIRE
CARGO LAMP CTRL
COMPUTER DATA LINES SYSTEM
COUPE
COURTESY LAMP CTRL
DOME/READING LAMP ENABLE SIG
GRN/BLK WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL WIRING HARNESS JUNCTION BLOCK
INTERIOR LAMP CTRL
LEFT FRONT FLOOR COURTESY LAMP
LEFT REAR CARGO CENTER COURTESY LAMP
LEFT UNDERHOOD LAMP
LIN BUS 12
RED/BRN WIRE
RED/VIO WIRE
RIGHT FRONT FLOOR COURTESY LAMP
RIGHT REAR CARGO CENTER COURTESY LAMP
RIGHT UNDERHOOD LAMP
WHT/VIO WIRE
Go to component -> Courtesy lamps circuit (1 of 2) -> ACCENT LIGHTING CTRL
