Trunk & fuel door release circuit, coupe for Chevrolet Corvette C6 (2004-2014)

Trunk & fuel door release circuit, coupe

Get access

BATT 1 FUSE 33 BLK WIRE BODY CONTROL MODULE (BCM) (MOUNTED ON TOE BOARD, IN RIGHT FOOTWELL) BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER INFORMATION CENTER (DIC) DISPLAY INSTRUMENT PANEL CLUSTER (IPC) EXTERIOR REAR COMPARTMENT LID RELEASE SWITCH FUEL DOOR RELEASE SWITCH FUEL DR RELSE RELAY GRY WIRE HOT AT ALL TIMES I/P FUSE BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) I/P RELAY BLOCK (IN RIGHT FRONT FOOTWELL, MOUNTED TO TOE BOARD) INTERIOR REAR COMPARTMENT LID RELEASE SWITCH LOGIC LOGIC CLASS 2 SER DATA LT BLU WIRE LT GRN WIRE ORG/BLK WIRE PNK RFA CLASS 2 SER DATA TRUNK REL SW SIG WIRE PNK WIRE PRW/WNDWS TRUNK/FUEL RELSE CIRCUIT BREAKER REAR COMPARTMENT LID PULLDOWN ACTUATOR (CENTER REAR OF COMPT LID) RED WIRE RED/WHT WIRE REMOTE CONTROL DOOR LOCK RECEIVER (RCDLR) (RIGHT SIDE OF DASH) TAN WIRE TRUNK RELSE FUSE UNDERHOOD FUSE BLOCK (ON RIGHT SIDE OF ENGINE COMPT) WHT WIRE WHT/BLK WIRE
